Industrypc SOM-6580
- Stock: In Stock
- Model: SOM-6580
- Dimensions: 80.00mm x 52.00mm x 0.00mm
190 samples sold
$499.00
| Basic Specifications | |
| SOC | SOM-6580 |
| CPU | Rockchip RK3568 |
| Graphic control | Mial-G52 |
| RAM | 2~8GB LPDDR4 |
| Storage | 1*eMMC,Max128GB 1*SATA3.0 |
| Display interface | 1*HDMI,1*single channel LVDS,MIPI DSI,1*MIPI DSI |
| HDMI Max 4096x2160@60Hz | |
| LVDS Max 1280*800@60Hz（1 × MIPI DSI 2560*1440@60fps） | |
| MIPI 1920*1080@60fps | |
| Web | 2*LAN |
| Realtek RTL8211F,10/100/1000Mbps | |
| USB | 1*USB3.0,1*USB3.0OTG，2*USB2.0 |
| Audio | 1*Headphone,1*MIC-IN |
| COM | 4*TTL，DEBUG |
| I/O | SMARC2.1 |
| Watchdog | support |
| OS | Android,Linux,Debian |
| Power | DC 5V |
| Temperature and humidity | Work Temperature:0℃～60℃ |
| Storage Temperature:-40℃～80℃ | |
| 5%～95%Humidity | |
| Size | 82mm x 50mm |
